Chilldyne Liquid Cooling System Calculator BETA
Assume 1 CPU / cold plate per node.
Note: This calculator is intended only to produce general estimates of the parameters involved in liquid-cooling a typical system with the specified inputs. It is not a substitute for a complete engineering design and analysis, and should not be used as a quotation tool. Results are supplied "as is" with no express or implied warranty of any kind.
Please contact us with the details of your system for more information about our cooling solutions.
Facility Inputs
| # | Description | Input | Units | |
|---|---|---|---|---|
| 1 | Facility Water Temperature | ? | °C |
Load Inputs
| # | Description | Input | Units | |
|---|---|---|---|---|
| 2 | Node Maximum Power | ? | W | |
| 3 | Desired Node Temperature | ? | °C |
Estimated Inputs
| # | Description | Input | Units | |
|---|---|---|---|---|
| 4 | CDU Approach | ? | °C | |
| 5 | CDU Flow Rate | ? | LPM | |
| 6 | Cold Plate Effectiveness | ? | % | |
| 7 | Coolant Specific Heat | ? | J/(kg*K) | |
| 8 | Coolant Density | ? | kg/m^3 | |
| 9 | Thermal Interface Resistance | ? | °C/W |
Results
| # | Description | Result | Units | |
|---|---|---|---|---|
| 10 | Node Flow Rate | ? | LPM | |
| 11 | Cold Plate Temperature Delta | ? | °C | |
| 12 | Cold Plate Thermal Resistance | ? | °C/W | |
| 13 | Node Inlet Temperature | ? | °C | |
| 14 | Node Outlet Temperature | ? | °C | |
| 15 | Number of Nodes | ? |
Please contact us with the details of your system for more information about our cooling solutions.
Calculator v0.3.2
